American Range Gas Ranges - AR-48G-DSB
Manual Control • 80,000 BTU • Dual 20" Storage Bases
Built for demanding commercial kitchens, the American Range AR-48G-DSB delivers a full-width, 1" thick steel griddle and generous base storage in one rugged 48" footprint. Fast heat recovery, rock-solid construction, and Made-in-USA reliability make this unit a powerhouse for breakfast, lunch, and dinner service.
Features
- Four 20,000 BTU cast-iron burners (one every 12") — 80,000 BTU total
-
1" thick polished steel plate for superior heat retention & even searing
- 3" wide grease trough with large front collector speeds daily clean-up
- (2) 20" storage bases keep pans, utensils, or dry goods at arm’s reach
- Stainless steel front, sides, landing ledge, & bull-nose for long-life durability
- Rear flue options (no up-charge):
- 6" stub back (standard)
- 20" backguard
- 24" high riser with shelf
- 6" chrome-plated adjustable legs for easy leveling
- Field convertible Natural or Propane gas — 3/4" NPT regulator supplied
- cETLus & ETL-Sanitation listed
- Designed, engineered & manufactured in the USA
Why Operators Choose American Range
- Manual control valves give chefs instant flame adjustment for precision cooking.
- 1" plate minimizes temperature drop when loading, cutting ticket times during rushes.
Specifications
| Model |
AR-48G-DSB |
| Gas Type |
Natural or Propane (field convertible) |
| Total BTU |
80,000 BTU/hr (24.0 kW) |
| Griddle Size |
48" W × 24" D (1,219 mm × 610 mm) |
| Plate Thickness |
1" (25 mm) polished steel |
| Number of Burners |
4 (manual control) |
| Overall Width |
48" (1,219 mm) |
| Overall Depth |
32-1/2" (826 mm) |
| Cooking Height |
36" (914 mm) on 6" legs |
| Rear Options |
6" stub back, 20" riser, or 24" high riser w/ shelf |
| Base Style |
(2) 20" storage compartments |
| Gas Connection |
3/4" NPT manifold • 5.0" W.C. Nat • 10.0" W.C. LP |
What our Experts Think
-
Commercial‑Grade 72″ Range Base – The American Range AR‑48G‑DSB is a heavy‑duty gas range top with a 48″ griddle cook surface paired with dual storage base cabinets (DSB) — perfect for kitchens that want maximum workspace and storage without built‑in ovens.
-
Large Flat‑Top Griddle Surface – A 48″ manual griddle with thick steel plate delivers even heat distribution and excellent retention for high‑volume foods like burgers, eggs, pancakes, and sandwiches.
-
Solid Burner Performance – Integrated open burners alongside the griddle provide flexible flame‑cooking capability for pots, pans, and sauté tasks.
-
Smart Storage Integration – Dual storage base cabinets keep cookware, sheet pans, and prep tools organized and within easy reach — reducing clutter and speeding up kitchen workflow.
-
Built for Commercial Kitchens – Stainless steel front and sides, adjustable legs, removable drip trays, and a deep landing ledge make this range durable and easy to clean under daily service conditions.
-
Safety & Certification – Designed to meet professional standards with cETLus and ETL‑Sanitation listings, ensuring compliance with commercial safety and hygiene requirements.
-
Expert Verdict: A versatile 72″ commercial gas range that blends a large griddle surface with reliable burners and smart storage — ideal for restaurants, diners, cafés, and catering kitchens needing efficient, multi‑zone cooking with space‑saving design.
Q&A
Q: What is the American Range AR‑48G‑DSB?
A: The American Range AR‑48G‑DSB is a 48″ commercial gas restaurant range with a 48″ manual griddle and dual storage bases (no ovens), designed for busy professional kitchens.
Q: What cooking surfaces does it include?
A: It features a 1″ thick steel griddle plate for even heat and multiple high‑output burners suitable for flat‑top cooking and searing.
Q: What is “DSB” and why is it useful?
A: “DSB” stands for Double Storage Base, meaning this model replaces ovens with two spacious base cabinets below the range for storing pans, utensils, dry ingredients, or prep supplies — helping streamline kitchen workflow.
Q: What materials and durability features does it have?
A: The range is built with stainless steel front, sides, and landing ledge, plus adjustable chrome‑plated legs for strength, corrosion resistance, and easy cleaning in high‑volume environments.
Q: How much total heat output does it deliver?
A: Typical configurations for this model deliver around 80,000 BTU total, optimized for reliable, continuous cooking on the griddle surface.
Q: Is the AR‑48G‑DSB certified for commercial use?
A: Yes — it carries cETLus and ETL‑Sanitation listings and is Made in the USA, meeting professional kitchen safety and hygiene standards.
Q: What kitchens is this range best suited for?
A: Ideal for restaurants, hotels, quick‑service kitchens, catering facilities, and institutional foodservice that need powerful griddle performance with added storage.
Maintenance Tips
-
Clean burners and grates regularly: Remove burner heads and brush debris to maintain strong 32,000 BTU flames and consistent cooking performance.
-
Maintain the 48" griddle: Scrape food residue after each use, wipe with warm water, and lightly oil to prevent rust and ensure even heat distribution.
-
Empty grease trays and drip pans: Clean frequently to reduce buildup, smoke, and fire hazards.
-
Wipe stainless steel surfaces: Use a soft cloth with mild detergent to keep the exterior sanitary and corrosion-resistant.
-
Clean oven interior weekly: Remove racks and wipe the porcelain-lined cavity to maintain even heat and prevent grease accumulation.
-
Inspect gas connections and controls: Check valves, fittings, and ignition components periodically for safe and reliable operation.
-
Ensure proper ventilation and leveling: Maintain adequate clearance around the range for safe high-BTU commercial operation.
