Marshall Electronics 3G-SDI Quad Viewer/Switcher - VMV4023GSH

Marshall Electronics  3G-SDI Quad Viewer/Switcher - VMV4023GSH

•  4x1 Seamless Switcher

• Ideal for remote productions, AV presentations, courtrooms, classrooms, and control rooms

• Allows smooth switching between 4 video inputs

•  Video Inputs & Outputs

• 4 x 3G-SDI inputs (Inputs 1 & 2 also support HDMI)

• Simultaneous 3G-SDI and HDMI outputs

• 3G-SDI output supports up to 1080p60 (4:2:2)

• HDMI output supports scaling up to UHD 4K

•  Format Flexibility

• Built-in scaler for up/down resolution and frame rate adjustment

• Accepts mixed input formats, conforms to selected output format (Format Fixer)

•  Multi-View & Monitoring

• Full-time quadview available via HDMI

• Use HDMI for local preview while SDI outputs up to 328 ft 📏

•  Professional Tools

• Waveform and vectorscope overlays for signal analysis

• Display quad labels for easy input identification

•  Control Options

• Front-panel button controls

• Remote control via Ethernet browser or RS-232

• Compatible with systems like Crestron

•  Design & Build

• Slim 1 RU rackmount design — perfect for flypacks

• Also suited for rugged "throw-down box" applications


What our Experts Think

• All‑in‑One Quad Viewer + Seamless Switcher
  The Marshall Electronics VMV‑402‑3GSH combines a 4×1 SDI switcher with a built‑in quad multiview display, letting you monitor four feeds and switch program output in one compact unit.

• Robust Multi‑Format Handling
  Accepts four 3G‑SDI inputs, with two supporting HDMI sources, and auto‑scales mixed formats/frame rates to a unified output—eliminating format mismatch headaches.

• Dual Program Outputs
  Simultaneous 3G‑SDI and HDMI program outputs provide flexible routing: use HDMI for local monitoring or a larger display while SDI feeds long‑distance runs.

• True Quad & Full Screen Control
  Full‑time quadview display via HDMI and instant full‑screen switching give operators both at‑a‑glance and focused source views without external gear.

• Professional‑Focused Tools
  Includes waveform/vector scope overlays, tally, and format scaling, making it ideal for broadcast control rooms, classrooms, courtrooms, or live events.

• Flexible Control Options
  Control via front panel, Ethernet browser interface, RS‑232, or IR remote—simplifying integration with automation systems like Crestron.

• Compact & Rugged 1RU Design
  Slim rackmount housing fits easily into production racks, flypacks, and AV installations with space constraints.

• Expert Verdict
  A versatile quad multiviewer and seamless switcher that delivers flexible connectivity, reliable scaling, and intuitive control—perfect for multi‑camera live production, broadcast monitoring, and AV installations requiring real‑time signal management.

Q&A

Q1: What is the VMV4023GSH used for?
A: It is a quad viewer and switcher that allows simultaneous monitoring of four 3G-SDI sources and easy switching between them.

Q2: What video inputs are supported?
A: Supports four 3G-SDI inputs, compatible with professional broadcast and AV systems.

Q3: What outputs does it provide?
A: Offers 3G-SDI and HDMI outputs, enabling connection to monitors, recorders, or streaming devices.

Q4: Can it display multiple sources at once?
A: Yes, it provides quad-view mode for all four sources and full-screen mode for individual inputs.

Q5: Are monitoring tools included?
A: Yes, it includes audio level meters, tally indicators, and on-screen labels for professional production monitoring.

Q6: Is it suitable for live production?
A: Absolutely, designed for live events, studios, and OB van workflows.

Q7: Does it allow seamless switching between sources?
A: Yes, it enables instant switching between inputs for smooth production operations.

Q8: Can it monitor audio?
A: Yes, embedded SDI audio can be monitored through on-screen meters.

Q9: Is the unit rack-mountable?
A: Yes, it fits standard 19-inch racks, making it ideal for professional AV setups.

Q10: Why choose the VMV4023GSH?
A: It offers quad-view monitoring, seamless switching, multi-output support, and embedded audio monitoring, making it ideal for professional multi-camera environments.
